I. Product - Related Information
(I) Specification Parameters
The two models of double steel tape armored flexible cables, Rvfv-K and Rvfav-K, have many commonalities in core specification parameters, and there are also some detailed differences.
The conductor cross - sectional specification is 240mm², which is the key to ensuring its current - carrying capacity. The 240mm² conductor cross - section enables the cable to have a current - carrying capacity of 400 - 500A. Such a current - carrying capacity can meet the power needs of large - scale industrial equipment, such as large - scale steelmaking equipment and heavy machinery. These equipment need a lot of power support when running, and the cable can stably transmit power for them. At the same time, it can also handle high - load power distribution systems, such as the main power distribution lines of large factories and the main power distribution circuits of large commercial complexes, ensuring that there will be no problems such as heating and power failure during power transmission due to insufficient current - carrying capacity.
In terms of voltage level, these two types of cables are usually applicable to 0.6/1kV low - voltage systems, which meet the standards of low - voltage power transmission, can be matched with common low - voltage power distribution equipment, and ensure the safety and stability of power transmission.
In terms of structural size, the outer diameter of the cable will be affected by factors such as the armor layer and the insulation layer. The double steel tape armor layer will make the outer diameter of the cable slightly larger than that of ordinary non -
Armored Cables, but due to the flexible design, its overall
Flexibility is not greatly affected. Taking a common structure as an example, after adding the insulation layer, sheath layer and double steel tape armor layer, the outer diameter of the cable is generally about 30 - 40mm. The specific size will vary slightly depending on the production process and material selection of different manufacturers.
In addition, the flame retardant grade of the two models of cables meets the relevant standards. In the flame retardant performance test, they can meet the requirements of not spreading combustion within a specified time and reducing the release of toxic smoke, providing a strong guarantee for fire safety.
(II) Characteristic Uses
Based on their own performance characteristics, Rvfv-K and Rvfav-K double steel tape armored flexible cables have extensive and important applications in many fields.
In large - scale industrial plants, such cables are very useful. Large - scale industrial equipment such as large - scale CNC machine tools and large - scale compressors have high requirements for the stability and continuity of power during operation. The 240mm² conductor cross - section can provide sufficient power, and the double steel tape armor layer can resist possible mechanical collisions and 挤压 in the plant area to avoid damage to the cable. Moreover, the wiring environment in the plant area is relatively complex, and sometimes it is necessary to shuttle and turn between equipment. The flexible design of the cable enables it to easily adapt to such laying scenarios and reduce the difficulty of wiring.
High - rise buildings are also an important application scenario. The internal structure of high - rise buildings is complex, and the power distribution lines need to be laid in narrow spaces such as walls and floors. The flexible design allows the cable to pass through these spaces smoothly. At the same time, high - rise buildings have high requirements for fire safety. The flame retardant characteristics of the cable can play an important role in case of fire, inhibiting the spread of fire along the cable and buying time for personnel evacuation and fire fighting. For example, the main power distribution lines of high - rise office buildings and high - rise residential buildings can choose such cables.
In the subway system, the use environment of cables is more special. The space in the subway tunnel is narrow, and there are vibrations and mechanical impacts. The double steel tape armor layer can protect the cable from these factors. The power distribution system of the subway has a large load, and the current - carrying capacity of 240mm² can meet the demand. The flexible design is convenient for laying and installation in the limited space of the tunnel. In addition, as a public transport place with a large number of people, fire safety is crucial for the subway, and the flame retardant characteristics of the cable are an important factor to ensure the safe operation of the subway.
The
Power Station field is also inseparable from such cables. There are a large number of power generation equipment and power distribution equipment in the power station, which need stable power transmission, and the large current - carrying capacity of the cable can meet this demand. There are many equipment in the power station, and the wiring may need to bypass various equipment. The flexible design makes the wiring more flexible. At the same time, the power station has strict requirements on the safety of equipment. The double steel tape armor layer can protect the cable from external factors, and the flame retardant characteristics can also reduce the fire risk.
In addition to the above main scenarios, such cables can also perform well in places such as large commercial complexes and large data centers, meeting their needs for high load, high safety and complex laying environments.
(III) Material and Style
The Rvfv-K and Rvfav-K double steel tape armored flexible cables fully consider performance and use needs in material selection and style design.
The conductor is made of high - purity copper. Copper has excellent conductivity, which can reduce energy loss during power transmission and ensure efficient power transmission. Moreover, copper has good ductility and toughness, which provides a basis for the flexible design of the cable, making the cable not easy to break when bent and better able to adapt to various laying scenarios.
The insulation layer usually uses materials with good temperature resistance and insulation performance, such as cross - linked polyethylene (XLPE). XLPE has high insulation resistance and voltage resistance, which can effectively isolate current and prevent electric leakage. At the same time, it also has good aging resistance and chemical corrosion resistance, which can maintain a stable insulation effect in different environments and extend the service life of the cable.
The sheath layer generally uses flame - retardant polyvinyl chloride (PVC) or other flame - retardant materials, which is an important guarantee for the cable to have flame - retardant characteristics. When the flame - retardant sheath comes into contact with a fire source, it can inhibit the combustion reaction, slow down the combustion speed, and release less toxic smoke during combustion, which can reduce harm to the human body and the environment. At the same time, the sheath layer can also protect the internal insulation layer and conductor from the external environment, such as preventing the invasion of moisture and dust.
The double steel tape armor layer is a major feature of the cable, which is made of high - quality low - carbon steel tape. Low - carbon steel tape has high mechanical strength, which can effectively resist external extrusion, collision and other impacts, and protect the internal core from damage. Moreover, the steel tape has been specially processed and has a certain degree of flexibility, so that the overall flexibility of the cable will not be lost due to the existence of the armor layer. The double steel tape design further enhances the protection ability of the armor layer, making the cable more durable in complex laying environments.
In terms of style, the cable has a circular structure as a whole. This structure has low resistance during laying, which is more convenient for both pipe laying and direct burial laying. The circular structure also makes the force on each part of the cable uniform, so that it can better bear external pressure. Due to the flexible design, the cable can be bent at a large angle, and the minimum bending radius can usually reach 6 - 8 times the outer diameter of the cable, which can adapt to laying scenarios with narrow spaces and multiple turns. The color of the cable is generally black. Black is not only resistant to dirt, but also can absorb heat, reducing the impact of direct sunlight on the cable.
(IV) Production Process
The production process of Rvfv-K and Rvfav-K double steel tape armored flexible cables is complex and rigorous, and each link has an important impact on the performance of the cable.
The production of the conductor is the first step in production. High - purity copper rods are selected as raw materials, and the copper rods are drawn into
Copper Wires with the required diameter through a wire drawing machine. During the wire drawing process, it is necessary to strictly control the wire drawing speed and the precision of the die to ensure that the diameter of the copper wire is uniform and the surface is smooth without burrs. After that, multiple copper wires are twisted together according to certain rules to form a conductor. The twisting process can enhance the flexibility of the conductor and ensure that the cross - sectional area of the conductor meets the requirement of 240mm². When twisting, it is necessary to control the twisting pitch. Too large or too small a pitch will affect the performance of the conductor. A suitable pitch can make the conductor bear uniform force when bending.
The next step is the extrusion of the insulation layer. The twisted conductor is sent to an extruder, and an insulating material such as cross - linked polyethylene is extruded on the outside of the conductor. During the extrusion process, it is necessary to accurately control parameters such as extrusion temperature, pressure and speed. Excessively high temperature will cause the decomposition of insulating materials and affect the insulation performance; excessively low temperature will make the insulation layer not closely combined with the conductor, which is easy to cause delamination. The extruded insulation layer should have a uniform thickness, a smooth surface, and no defects such as bubbles and impurities to ensure a good insulation effect.
After the insulation layer is completed, the sheath layer is extruded. The sheath material is flame - retardant material, and the sheath layer is extruded on the outside of the insulation layer through an extruder. It is also necessary to control the extrusion parameters to ensure that the sheath layer has a uniform thickness and is closely combined with the insulation layer. The thickness of the sheath layer should meet the relevant standards, which can not only play a protective role, but also not excessively increase the outer diameter and weight of the cable.
Then comes the production of the armor layer. The double steel tape is wrapped around the outside of the sheath layer through an armoring machine to form a double steel tape armor layer. When wrapping, it is necessary to ensure that the tension of the steel tape is uniform and the wrapping is tight, and there should be no loosening or wrinkles. The overlapping width of the steel tape should meet the requirements, generally 1/3 - 1/2 of the width of the steel tape, which can ensure the integrity and protective performance of the armor layer. At the same time, during the wrapping process, attention should be paid to protecting the sheath layer to avoid scratches on the sheath by the steel tape. Since the cable needs to be flexible, it is necessary to control the wrapping angle and tension of the steel tape during the armoring process to ensure that the armored cable can still maintain good flexibility.
Finally, there is the finished product inspection link. A comprehensive inspection is carried out on the appearance, size, conductor resistance, insulation resistance, voltage resistance performance and flame retardant performance of the cable. The appearance inspection mainly checks whether the surface of the cable is smooth and whether there are damages and deformations; the size inspection includes the conductor cross - sectional area, insulation layer thickness, sheath layer thickness, armor layer thickness, etc.; the electrical performance inspection ensures that the conductive and insulation performance of the cable meet the standards; the flame retardant performance inspection verifies the flame retardant effect of the cable when it comes into contact with a fire source through special testing equipment. Only cables that pass all inspection items can be sold.
II. General Product Information
(I) Packaging
In order to ensure that Rvfv-K and Rvfav-K double steel tape armored flexible cables are not damaged during transportation and storage, the packaging link is crucial.
Such cables are usually packaged with cable reels, which are divided into wooden and steel types. Because the cable itself has a double steel tape armor layer and has a certain weight, steel cable reels are generally used for cables with longer lengths. Steel cable reels have strong load - bearing capacity, can bear the weight of the cable, and have a solid structure, which is not easy to be damaged during transportation and can effectively protect the cable. For cables with shorter lengths, wooden cable reels can also be used. Wooden cable reels have relatively low cost, light weight and are more convenient to carry.
When packaging, first wind the cable neatly on the cable reel, and maintain appropriate tension during the winding process to avoid loosening of the cable. After winding, wrap a layer of plastic film on the outer layer of the cable. The plastic film can play a role in moisture proofing and dust proofing, preventing the cable surface from being polluted and corroded. Although the steel tape armor layer itself has a certain protective capacity, attention should still be paid to avoiding collision with other hard objects during packaging. Protective devices can be installed on the edge of the cable reel.
The cable reel will clearly mark the model, specification (such as 240mm²), length, production date, manufacturer, flame retardant grade and other information of the cable, which is convenient for users to identify and check when receiving and storing. At the same time, product qualification certificates, test reports and other relevant documents will be attached to prove that the quality of the cable meets the standard requirements.
(II) Transportation
When transporting Rvfv-K and Rvfav-K double steel tape armored flexible cables, many aspects need to be paid attention to to ensure that the cables arrive at their destination safely.
When loading the cable, use appropriate hoisting equipment, such as cranes and forklifts, to hoist the cable reel smoothly to the transport vehicle. Special hoisting tools should be used for hoisting to avoid damaging the cable reel and the cable. On the transport vehicle, the cable reel should be fixed firmly. Steel wire ropes and fastening belts can be used to fix the cable reel on the load - bearing frame of the vehicle to prevent the cable reel from rolling and shifting due to vehicle bumps, turns, sudden braking and other situations during transportation. When fixing, attention should be paid to moderate force. It is necessary to ensure firmness and not excessively squeeze the cable reel to avoid damaging the cable.
During transportation, choose routes with better road conditions and try to avoid bumpy and rugged roads. Transport vehicles should drive smoothly, avoid sudden acceleration, sudden braking and sharp turns, and reduce the impact on the cable. If it is a long - distance transportation, regularly check the fixing of the cable reel and the packaging of the cable, and deal with problems in time if found.
Environmental factors should also be paid attention to during transportation. In case of bad weather such as rainy and snowy days, cover the cable with rainproof cloth to prevent rainwater and snowwater from entering the cable and affecting the insulation performance of the cable. When transporting in summer, avoid long - term exposure of the cable to sunlight to prevent aging of the sheath layer due to high temperature; when transporting in winter, pay attention to keeping warm to avoid cracking of the cable due to material embrittlement in low - temperature environments.
In addition, during transportation, avoid collision between the cable reel and other goods. If multiple cable reels are transported at the same time, a certain distance should be kept between the cable reels, and isolation measures should be taken to prevent mutual collision and damage.
(III) Delivery
The delivery link requires rigorous operation to ensure that the cable is delivered to the customer accurately and in a timely manner.
After receiving the customer's order, the staff shall check the order information in the first time, including the model (Rvfv-K or Rvfav-K), specification (240mm²), quantity, delivery address, delivery time of the cable, etc., to ensure that the information is accurate. After checking, retrieve the corresponding cable from the warehouse, and conduct a pre - delivery inspection on the cable, checking whether the packaging is intact, the logo is clear, and the relevant documents are complete, so as to ensure that the delivered cable meets the order requirements and quality standards.
According to the customer's delivery time and address, select a suitable logistics company and transportation method. For urgent orders, priority shall be given to arranging expedited transportation to ensure delivery within the specified time. When handing over to the logistics company, inform the logistics company of the relevant information of the cable (such as model, specification, quantity, etc.) and instruct it to pay attention to protecting the cable during transportation. At the same time, go through relevant transportation procedures, such as filling in the waybill and signing the transportation contract.
After delivery, promptly inform the customer of the delivery information, including the name of the logistics company, the waybill number, and the estimated arrival time, so that the customer can track the transportation status of the goods in real time and prepare for receipt. If abnormal situations occur during transportation, such as delayed delivery or damage to the goods, communicate with the logistics company in a timely manner, feed back the situation to the customer, and actively coordinate to solve the problem.
(IV) Samples
In order for customers to intuitively understand the quality and performance of Rvfv-K and Rvfav-K double steel tape armored flexible cables before bulk purchase, it is necessary to provide sample services.
Customers can put forward sample requirements to the manufacturer and specify the model, specification and other information of the required samples. After receiving the sample requirements, the manufacturer will prepare the corresponding samples within the specified time. The length of the sample is generally 1 - 2 meters, which can meet the customer's inspection of the cable's appearance, structure, flexibility, armor layer quality and other aspects.
When preparing samples, ensure that the samples are consistent with mass - produced products in terms of materials, processes and performance. The samples are simply packaged, such as wrapped with plastic film, and the model, specification, production batch and other information of the samples are marked on the package. At the same time, attach the test report of the sample, including the test results of conductor resistance, insulation resistance, flame retardant performance, etc., so that customers can fully understand the quality of the sample.
Samples are usually sent to customers by express. Choose a reputable express company with fast transportation speed to ensure that the samples can be delivered to customers quickly and safely. After sending the samples, promptly inform the customer of the express waybill number to facilitate the customer to query the logistics information of the samples. After the customer receives the samples, the manufacturer can take the initiative to communicate with the customer, understand the customer's feedback on the samples, and answer the customer's questions. If the customer has suggestions for improving the samples, the manufacturer can optimize according to the suggestions.
(V) After - sales Service
Perfect after - sales service is an important support to ensure customers' use of Rvfv-K and Rvfav-K double steel tape armored flexible cables.
During the cable installation process, if the customer encounters
technical problems such as laying methods and connection methods, they can contact the after-sales service personnel of the manufacturer by phone, email, online customer service, etc. After-sales service personnel will promptly provide professional technical guidance, such as providing installation manuals and video tutorials. If necessary, technical personnel can be arranged to guide the installation on-site to ensure the installation quality.
If the cable has quality problems during use, customers can feedback to the manufacturer. The manufacturer will arrange professional personnel to investigate the problem and determine the cause of the problem. If the failure is caused by the product's own quality problems and is within the warranty period, the manufacturer will provide repair, replacement and other services for the customer in accordance with relevant regulations. The warranty period is generally 1-5 years, and the specific period depends on the product model and usage scenario.
The manufacturer will also conduct regular return visits to customers to understand the use of cables and collect customers' opinions and suggestions. Based on customer feedback, continuously improve product quality and service levels. At the same time, provide customers with cable maintenance suggestions, such as regularly checking the appearance and insulation performance of the cable, avoiding excessive extrusion and high temperature of the cable, so as to extend the service life of the cable.
In addition, the manufacturer will provide customers with relevant technical support for the product, such as query services for cable performance parameters and usage environment requirements, to help customers better use and manage the cable. If customers have return and exchange needs after bulk purchase, the manufacturer will handle them in a timely manner in accordance with relevant regulations to protect the legitimate rights and interests of customers.
