Na2xy Na2xh Power Cables 0.6/1kv XLPE Insulated PVC or LSZH Sheathed Non-Armoured Aluminium Low Voltage

1. Technical Specifications

• Voltage Rating: 0.6/1kV AC system

• Conductor: Aluminum (IEC 60228 compliant)

• Insulation: Cross-linked polyethylene (XLPE)

• Sheath Options:

• NA2XY: PVC Sheath

• NA2XH: LSZH sheath

• Size Range: 1.5mm² to 630mm²

• Temperature Rating: 90℃ continuous/250℃ short-circuit

• Bending Radius: ≥6×cable diameter

• Certifications:

• PVC: RoHS

• LSZH: IEC 60754, IEC 61034

2. Key Features

• Safety: LSZH meets strict fire requirements

• Electrical Performance: Insulation resistance ≥100MΩ·km

• Mechanical Strength: Tensile strength ≥10N/mm²

• Easy Installation: Lightweight and flexible

• Typical Applications:

• Commercial building distribution

• Public spaces (subways, airports)

• Industrial power supply

• Sensitive locations (hospitals, schools)

• Service Life: Over 30 years

3. Manufacturing Process

• Compact round Stranded Conductor

• CCV cross-linking production line

• Triple-layer co-extrusion insulation

• Automated sheath extrusion

• 100% partial discharge test(≤10pC)

• Full traceability quality system

• Stringent smoke density test (LSZH)

4. Packaging & Shipping

• Standard Packaging:

• Small sizes: Plastic drums

• Large sizes: Steel-wood waterproof drums

• Package Length:

• 1.5-95mm²: 1000m/drum

• 120-240mm²: 500m/drum

• 300-630mm²: 300m/drum

• Shipping Methods: Container/Ocean freight

• UV-resistant packaging available

5. After-sales Service

• Warranty: 36-month quality guarantee

• Technical Support: Free consultation

• Installation Guidance: Layout design provided

• Samples: Free samples up to 20m

• Response Time: 24-hour support

• Value-added: Cable selection advice

• Emergency Service: 72-hour delivery for urgent orders
