I. Information Related to the Product Itself
(1) Specification Parameters
The N2X-Oh Cable 3*240mm² copper power building cable has clear and detailed settings in terms of specification parameters to meet the stringent requirements of building power systems.
The cable adopts a 3-core design, with each core conductor having a precise cross-sectional area of 240mm². This cross-sectional area enables the cable to have a strong current-carrying capacity. In a standard environment, its long-term allowable current-carrying capacity can reach approximately 310 amperes, which can easily meet the power needs of high-power equipment in buildings, such as large central air conditioning hosts and high-rise elevator groups.
The rated voltage is 0.6/1kV, and this voltage level perfectly adapts to various low-voltage power distribution scenarios in buildings. Whether it is the complex power distribution system of a commercial building or the power transmission network of a large residential community, it can operate stably, ensuring efficient transmission of electricity from the distribution room to various electrical terminals.
The outer diameter of the cable is precisely controlled within a reasonable range, usually about 65 millimeters. This size design not only ensures the stability of the internal structure of the cable but also facilitates laying and installation in limited spaces such as building walls, cable trays, and pipelines. Its bending radius is not less than 12 times the cable diameter, that is, the minimum radius during bending must reach more than 780 millimeters. This parameter ensures that the cable will not damage the internal structure due to excessive bending during laying, which affects its performance.
In addition, the conductor DC resistance of the cable at 20°C is not greater than 0.0741Ω/km. This extremely low resistance value further confirms its excellent electrical conductivity, which can effectively reduce power loss during transmission and improve power utilization efficiency.
(2) Characteristic Uses
The N2X-Oh Cable 3*240mm² copper power building cable has extensive and important applications in various construction projects due to its excellent performance.
In commercial buildings, the power demand is complex and the load is large. This cable can be used as the main power distribution trunk to transmit electricity from the main distribution room of the building to the distribution rooms on each floor. Large central air conditioning systems, high-end elevator equipment, dense office electrical equipment in commercial buildings all require stable and strong power support. This cable can easily meet these needs and ensure the normal operation of various businesses in the building. For example, in some super high-rise commercial buildings, the operation of elevators depends on stable power supply. This cable can provide continuous power for the main elevator system, avoiding safety accidents such as elevator shutdown due to power interruption.
Office buildings also have high requirements for the stability and reliability of electricity. This cable can be used for main circuit transmission in office buildings to provide power for office equipment such as computers, printers, copiers, as well as lighting systems and air conditioning systems in the office building. Its excellent electrical conductivity and low loss characteristics can reduce the power cost of the office building, while ensuring the power stability of the office environment and improving work efficiency.
The power demand of large residential communities involves the daily life of many families. This cable can be used as the main power
Transmission Cable of the community to transmit electricity to the distribution facilities of each residential building. The normal operation of various electrical equipment in residents' homes, such as refrigerators, TVs, air conditioners, water heaters, is inseparable from stable electricity. This cable can ensure the stable transmission of electricity and avoid the impact of power fluctuations on residents' lives. Especially during the peak electricity consumption periods in summer and winter, when a large number of electrical appliances are running at the same time, the strong current-carrying capacity of this cable can cope with this situation and ensure the normal electricity use of residents.
In addition to the above main application scenarios, the cable is also suitable for some large public buildings, such as gymnasiums and convention centers. These places often need a large number of temporary electrical equipment when holding large-scale events. This cable can be used as the main cable of the temporary power supply system to provide reliable power support for these equipment, ensuring the smooth progress of the events.
(3) Material and Style
The N2X-Oh Cable 3*240mm² copper power building cable fully considers the needs of building power transmission in material selection and style design, combining performance and practicality.
The conductor uses high-purity electrolytic copper with a purity of more than 99.95%. This high-purity copper material has many advantages. Firstly, its electrical conductivity is extremely excellent, with a conductivity of up to 58MS/m or more, which can minimize power loss during transmission and improve power transmission efficiency. Secondly, high-purity electrolytic copper has good ductility, which can withstand a certain degree of bending and stretching during cable production and laying, and is not easy to break, ensuring the integrity of the cable. In addition, it also has excellent oxidation resistance. During long-term use, the surface of the conductor is not easy to oxidize to form an oxide layer, which reduces the resistance increment at the joint and prolongs the service life of the cable.
The insulation layer is made of cross-linked polyethylene (XLPE) material, which is a high-quality
Insulation Material commonly used in
Power Cables. It has excellent aging resistance, can maintain good insulation performance during long-term use, and is not easy to age and deteriorate over time. Its temperature resistance range is wide, can withstand temperature changes from -40°C to 90°C, and can adapt to the complex temperature environment inside the building. Whether in cold winter or hot summer, it can maintain a stable insulation effect. At the same time, cross-linked polyethylene material has strong resistance to mechanical wear. During building construction, the cable may be subjected to mechanical effects such as wall extrusion and cable tray friction. The insulation layer can effectively resist these wears and protect the conductor from damage.
The sheath of the cable is made of polyvinyl chloride (PVC) material, which tightly wraps around the outside of the insulation layer, forming a strong protective barrier. Polyvinyl chloride material has good mechanical strength and corrosion resistance, which can protect the internal structure of the cable from the influence of the external environment, such as preventing moisture, dust, corrosive gases, etc. from entering the inside of the cable, ensuring the normal operation of the cable. In addition, the sheath also has a certain flame retardant performance. In case of fire and other accidents, it can delay the spread of the fire and gain time for personnel evacuation and fire fighting.
In terms of style, the cable has a circular structure with an overall compact design. The circular structure makes the cable bear force evenly during laying, facilitating 穿梭 in narrow spaces such as cable trays and pipelines, and reducing laying difficulty. The surface of the cable is smooth and flat, with no obvious protrusions or depressions. This design is not only beautiful but also can reduce friction with other objects during laying, reducing the risk of cable damage. At the same time, the smooth surface is also easy to clean and maintain.
(4) Production Process
The production process of N2X-Oh Cable 3*240mm² copper power building cable strictly follows high-standard production processes to ensure that each section of the cable has excellent quality.
The first step is the conductor preparation process. High-purity electrolytic copper rods are selected as raw materials. After cleaning to remove surface impurities and oil, they enter the wire drawing process. During the wire drawing process, through a series of dies of different specifications, the copper rods are drawn into
Copper Wires of the required diameter. In the wire drawing process, it is necessary to precisely control the wire drawing speed and the temperature of the die to ensure that the diameter of the copper wire is uniform, the surface is smooth, and at the same time, the copper wire has good mechanical properties and electrical conductivity. After wire drawing, multiple copper wires are stranded to form a conductor core. During the stranding process, it is necessary to control the stranding pitch and tension to ensure that the structure of the conductor core is stable and the electrical conductivity is uniform.
The next step is the extrusion process of the insulation layer. The prepared conductor core is sent to the extruder, and a layer of cross-linked polyethylene (XLPE) insulation layer is extruded outside the conductor core. Before extrusion, it is necessary to pretreat the cross-linked polyethylene material to remove moisture and impurities. During the extrusion process, it is necessary to strictly control the extrusion temperature, pressure and speed to ensure that the thickness of the insulation layer is uniform, closely combined with the conductor core, and free of defects such as bubbles and impurities. After the extrusion of the insulation layer is completed, cross-linking treatment is required. By heating, the cross-linked polyethylene molecules undergo a cross-linking reaction to form a three-dimensional network structure, thereby improving the temperature resistance, aging resistance and mechanical strength of the insulation layer.
Then is the cabling process. The three wire cores with completed insulation layer extrusion are stranded according to a certain stranding method to form the core of the three-
Core Cable. During the stranding process, it is necessary to precisely control the stranding pitch and tension to ensure that the core structure is stable and the shape is regular. At the same time, during the stranding process, filling materials will be added in the middle of the core to make the structure of the core more compact and improve the roundness of the cable.
Finally, the sheath extrusion and finished product inspection processes are carried out. The
Stranded Core is sent to the sheath extruder, and a layer of polyvinyl chloride (PVC) sheath is extruded outside the core. During the extrusion process, it is also necessary to control the extrusion parameters to ensure that the thickness of the sheath is uniform, the surface is smooth, and it is closely combined with the core. After the sheath extrusion is completed, the cable undergoes a series of strict inspections, including appearance inspection, size measurement, conductor DC resistance test, insulation resistance test, voltage resistance test, etc. Only cables that pass all inspection items can be judged as qualified products and sold on the market.
II. General Product Information
(1) Packaging
In order to ensure that the N2X-Oh Cable 3*240mm² copper power building cable is not damaged during transportation and storage, a scientific and reasonable packaging method is adopted.
For coiled cables, wooden cable reels are usually used for packaging. The wooden cable reels are made of high-quality hardwood, which has high strength and stability, and can bear the weight of the cable and the external impact during transportation. The cable is tightly wound on the cable reel, and the tension is strictly controlled during the winding process to avoid loosening or excessive stretching of the cable. On the outside of the cable reel, a thick layer of moisture-proof plastic film is wrapped, which can effectively prevent moisture, rainwater, etc. from invading the cable and protect the insulation layer and conductor of the cable from moisture damage. At the same time, the model, specification, length, weight, production date, manufacturer and other information of the product will be clearly marked on the side of the cable reel, which is convenient for users to identify and manage during receiving and storage.
For some small-length cables or samples, strong cartons are used for packaging. The cartons are made of high-strength corrugated paper, which has certain compressive performance. Inside the carton, moisture-proof paper and buffer materials such as foam boards and bubble films are placed. These materials can reduce the vibration and collision of the cable during transportation and protect the appearance and performance of the cable from damage. The outside of the carton is also printed with relevant product information, which is convenient for handling and storage.
During the packaging process, the two ends of the cable will also be sealed, usually with special plastic end caps or sealing tape to prevent dust, impurities, etc. from entering the inside of the cable and affecting the performance of the cable.
(2) Transportation
The transportation of N2X-Oh Cable 3*240mm² copper power building cable requires a series of strict measures to ensure the safety and integrity of the cable.
The choice of transport vehicles is crucial, and trucks or trailers in good condition with sufficient load-carrying capacity should be selected. Before loading the cable, the carriage of the vehicle should be thoroughly cleaned to ensure that there are no sharp objects, corrosive substances, etc. in the carriage, so as not to damage the packaging of the cable and the cable itself. For coiled cables, special hoisting equipment is used for loading and unloading. During the hoisting process, the cable reel should be kept stable to avoid violent shaking and collision. After placing the cable reel in the carriage, it should be firmly fixed with strong ropes or chains to prevent sliding, rolling, etc. during transportation.
During transportation, the cable should be protected from direct sunlight, rain, high temperature, low temperature and other extreme environments. For long-distance transportation, it is necessary to cover the cable with a tarpaulin to protect the cable from damage by the external environment. At the same time, the transportation route should be reasonably planned, and roads with good and flat conditions should be chosen as much as possible to reduce 颠簸 and vibration during transportation. During transportation, the driver should stop regularly to check the fixing of the cable and whether the packaging is intact. If any abnormal situation is found, measures should be taken in time to deal with it to ensure that the cable can reach the destination safely.
In addition, traffic rules must be observed during transportation, driving at a limited speed, avoiding sudden braking, sharp turns and other operations to reduce the impact on the cable. For some special road sections, such as bridges and tunnels, attention should be paid to height limits, weight limits and other regulations to ensure transportation safety.
(3) Delivery
The company has established a complete delivery process to ensure that customers can receive the N2X-Oh Cable 3*240mm² copper power building cable in a timely and accurate manner.
After the customer places an order, the sales department will promptly enter the order information into the system and transfer it to the warehouse department. Warehouse staff will accurately find cables of the corresponding model, specification and length in the warehouse according to the order information. During the search process, a preliminary inspection will be carried out on the packaging and labels of the cable to ensure that the product information is consistent with the order.
After finding the corresponding cable, the warehouse staff will recheck the cable, including model, specification, length, quantity, etc. After confirmation, the cable will be repackaged according to the packaging standards (if necessary) to ensure that the packaging is intact. Then, go through the outbound procedures, generate an outbound order, and enter the outbound information into the system to facilitate the tracking and management of the goods.
The warehouse department will notify the logistics department of the delivery information. The logistics department will select appropriate transportation methods and vehicles according to the quantity, weight, volume and destination of the goods, and sign a transportation contract with the transportation company to clarify the rights and obligations of both parties. After the transportation company arranges the vehicle, it will contact the warehouse department in time to agree on the loading time.
During the loading process, warehouse staff will cooperate with the personnel of the transportation company to safely load the cable onto the transport vehicle and recheck the fixing of the cable. After loading, the warehouse staff will hand over the outbound order and other relevant documents to the transport driver, and promptly feed back the delivery details, such as the name of the transportation company, license plate number, driver's contact information, estimated arrival time, etc., to the customer, so as to facilitate the customer's preparation for receiving the goods.
After delivery, the company will track the transportation status of the goods and keep abreast of the location and transportation of the goods through the logistics information system. If any transportation abnormality is found, it will promptly communicate and coordinate with the transportation company to ensure that the goods can be delivered on time.
(4) Samples
In order to allow customers to better understand the performance and quality of N2X-Oh Cable 3*240mm² copper power building cable, the company provides sample services.
Customers can apply for samples from the sales department through various means such as the company's official website, telephone, and email. When applying, it is necessary to provide the customer's basic information, such as company name, contact person, contact number, address, etc., as well as the model, specification and quantity of the required samples.
After receiving the sample application, the sales department will review it within 1-3 working days. The review content includes the customer's qualifications, the rationality of the demand, etc. After the review is passed, the sales department will contact the customer to confirm the relevant matters of the sample, such as whether the sample is charged and the way of freight bearing. For samples of conventional specifications, the company usually provides them free of charge, but the freight shall be borne by the customer; for specially customized samples, a certain sample fee may be charged, and the specific fee will be negotiated with the customer.
After the customer confirms the sample matters and pays the relevant fees (if any), the company will arrange for the sample to be sent as soon as possible. The packaging of the sample is the same as that of the formal product to ensure that the sample is not damaged during transportation. After the sample is sent, the sales department will promptly inform the customer of the courier tracking number and other information to facilitate the customer to check the logistics status of the sample.
After receiving the sample, the customer can conduct a comprehensive inspection and test on the sample, such as appearance inspection, size measurement, conductivity test, insulation performance test, etc. If there are any questions or opinions about the sample, they can communicate with the sales department in a timely manner, and the company's technical personnel will provide professional answers and technical support for the customer. Through the inspection and test of the sample, customers can more intuitively understand the performance and quality of the product, providing a reference for subsequent purchasing decisions.
(5) After-sales Service
The company attaches great importance to after-sales service and provides customers with comprehensive after-sales guarantees to ensure customer satisfaction in the process of using N2X-Oh Cable 3*240mm² copper power building cable.
In terms of product quality assurance, the company promises that all cables sold are qualified products, in line with relevant national standards and industry standards, such as GB/T 12706, and provides a 12-month quality guarantee period. During the quality guarantee period, if the cable has quality problems caused by non-human factors, such as conductor breakage, insulation layer aging and damage, etc., the customer can submit a return or exchange application to the company. After receiving the application, the company will arrange professional technicians to conduct on-site testing and verification. If it is confirmed to be a quality problem, the company will promptly handle the return or exchange procedures for the customer and bear the relevant transportation costs.
In terms of technical support, the company has a professional technical team to provide customers with comprehensive technical guidance. If customers encounter any technical problems during the laying, installation and use of the cable, they can contact the company's technical personnel through telephone, email, online consultation, etc. The technical personnel will reply within 24 hours and provide detailed solutions. For some complex technical problems, the company can arrange technical personnel to go to the site for guidance and handling to ensure that the problems are solved in a timely manner. For example, during the cable laying process, customers may have questions about the bending radius and laying methods. The technical personnel will provide professional suggestions and guidance according to the on-site situation to ensure that the cable laying meets the specification requirements.
The company has also established a complete customer file and conducts regular return visits to customers' usage. During the return visit, the company will understand the operation status of the cable, the customer's use experience and existing problems, and provide customers with necessary maintenance suggestions and maintenance knowledge. For example, remind customers to conduct regular 外观 inspections of the cable, clean up the debris around the cable, and avoid mechanical damage to the cable. Through regular return visits, the company can timely grasp the usage of the product and continuously improve the product and service quality.
In addition, the company also provides cable maintenance and repair services. If the cable fails during use, customers can contact the company's after-sales service department, and the company will arrange professional maintenance personnel for repair. For some faults that cannot be repaired, the company will provide return or exchange services in accordance with relevant regulations.
The company has always adhered to the tenet of "customer first, service first", continuously improved the quality of after-sales service, provided reliable guarantees for customers, and let customers have no worries in the process of using the product.
