LV Copper Power Cable Cu/XLPE/PVC 600/1000 V Black Cream Hard Electrical Cable Cobre

تصنيفها：

كابل الجهد المنخفض
يشارك：
رمز الاستجابة السريعة:
وقت الإصدار：

2025-07-01 05:53:43

التحقيق الفوري

مقدمة المنتج

Technical Specification for LV Copper Power Cable (Cu/XLPE/PVC)

1. Product Overview

This 600/1000V rated Copper Power Cable features XLPE insulation and PVC Sheath, available in standard black or custom cream color. Suitable for fixed wiring installations in buildings and industrial facilities.

2. Construction

Layer	Material	Specifications
Conductor	Annealed copper	IEC 60228 Class 2 compliant
Insulation	XLPE	Thickness: 0.7-1.4mm
Sheath	PVC	Thickness: 1.5-2.5mm, flame retardant

3. Technical Data

CSA(mm²)	Conductor	Insul.Thk(mm)	SheathThk(mm)	OD(mm)
1.5	7/0.52	0.7	1.5	4.5
2.5	7/0.68	0.7	1.5	4.9
4	7/0.85	0.8	1.6	5.6

4. Electrical Performance

Rated voltage: 600/1000V
Test voltage: 3500V/5min
Insulation resistance: ≥100MΩ·km @20℃
Current rating (in air @30℃):

1.5mm²: 18A
2.5mm²: 25A
4mm²: 34A

5. Mechanical Properties

Min bending radius: 6×OD
Tensile strength: ≥12.5N/mm²
Elongation at break: ≥150%
Flame retardancy: IEC 60332-1

6. Installation Guide

Installation temp: ≥0℃
Operating temp: -15℃ to +70℃
Applications:

Building Wiring
Industrial equipment
Lighting circuits
Socket connections

7. Certifications

IEC 60502-1
GB/T 12706.1
CE Marking
RoHS Compliance
