I. Product-Specific Details
1. Specification Parameters
The aluminum core, single-stranded, PVC insulated, PVC
Sheathed Cable is engineered with precise specifications to ensure optimal performance across diverse electrical applications. These parameters are critical for determining the cable’s suitability for specific projects, from residential wiring to industrial power distribution.
Conductor Characteristics
The core of the cable consists of a single-stranded
Aluminum Conductor, which is defined by its diameter, cross-sectional area, and conductivity. Common conductor sizes range from 1.5 mm² to 240 mm², accommodating current ratings from 10 A to 400 A, depending on the application and installation conditions. The single-stranded design ensures uniformity in electrical flow, minimizing resistance and energy loss. The aluminum used is typically 99.5% pure, with trace elements (such as copper or magnesium) added to enhance tensile strength and corrosion resistance. This alloy composition ensures the conductor can withstand mechanical stress during installation and maintain conductivity over time.
Insulation and Sheathing Dimensions
The
PVC Insulation layer surrounding the aluminum core has a thickness ranging from 0.6 mm to 3.0 mm, depending on the conductor size and voltage rating. This layer is designed to provide dielectric strength of at least 15 kV/mm, ensuring safe operation at voltages up to 600 V for general-purpose cables and up to 1000 V for industrial applications. The outer
PVC Sheath adds an additional 0.8 mm to 4.0 mm in thickness, contributing to the cable’s overall diameter, which ranges from 3.5 mm (for 1.5 mm² conductors) to 30 mm (for 240 mm² conductors).
Voltage and Temperature Ratings
The cable is rated for nominal voltages of 0.6/1 kV (phase-to-ground/phase-to-phase), making it suitable for low-voltage power distribution systems. It operates efficiently within a temperature range of -20°C to +70°C, with short-term overload capacity up to +90°C for durations not exceeding 5 seconds. This temperature tolerance ensures reliable performance in both cold climates (e.g., outdoor installations in winter) and warm environments (e.g., indoor wiring in poorly ventilated spaces).
Mechanical Properties
The cable exhibits a minimum bending radius of 6 times its outer diameter for fixed installations and 10 times for flexible applications, allowing for easy routing around obstacles. Its tensile strength is rated at 12 N/mm² for the conductor and 15 N/mm² for the PVC layers, ensuring resistance to stretching during installation. Additionally, the cable is flame-retardant, meeting IEC 60332-1-2 standards, which require it to self-extinguish within 60 seconds of removing an ignition source.
2. Unique Applications
The versatility of this cable stems from its ability to adapt to both indoor and outdoor environments, making it a preferred choice across residential, commercial, industrial, and infrastructure sectors.
Residential Applications
In homes, the cable is used for main power supply lines, connecting distribution boards to outlets, lighting fixtures, and major appliances (e.g., refrigerators, air conditioners). Its single-
Stranded Conductor simplifies termination in junction boxes, while the PVC sheathing protects against accidental damage from furniture or renovation work. For outdoor residential use, it is ideal for wiring garden lighting, pool pumps, and outdoor sockets, as the sheath resists moisture and UV radiation.
Commercial Buildings
In offices, shopping malls, and hotels, the cable facilitates power distribution to HVAC systems, elevators, security cameras, and POS terminals. Its flame-retardant properties are crucial in high-occupancy spaces, reducing fire risks. The cable’s
Flexibility allows it to be installed in tight spaces, such as ceiling cavities and wall ducts, without compromising performance.
Industrial Facilities
Factories and manufacturing plants rely on this cable for powering machinery, conveyor belts, and control systems. Its resistance to oils, chemicals, and mechanical stress makes it suitable for harsh industrial environments. For example, in food processing plants, the PVC sheath withstands frequent cleaning with water and sanitizers, while in automotive factories, it resists exposure to lubricants and coolants.
Infrastructure Projects
The cable is widely used in infrastructure, including street lighting, traffic signal systems, and underground power distribution networks. Its durability makes it suitable for direct burial (with proper bedding) in soil or concrete, protecting against rodent damage and soil pressure. Overhead installations, supported by poles or brackets, benefit from its lightweight design, reducing strain on support structures.
3. Material and Design Features
The cable’s performance is directly influenced by its material composition and structural design, which work in tandem to ensure safety, efficiency, and longevity.
Aluminum Conductor
Aluminum is chosen for its favorable strength-to-weight ratio (2.7 g/cm³, compared to copper’s 8.96 g/cm³), reducing installation labor and transportation costs. While its conductivity (377 S/m) is lower than copper’s (580 S/m), the larger cross-sectional area of
Aluminum Conductors compensates, ensuring equivalent current-carrying capacity at a lower cost. The single-stranded design eliminates the need for stranding, simplifying manufacturing and reducing the risk of internal corrosion between strands.
PVC Insulation
The insulation layer is made from rigid PVC compound, formulated with plasticizers to enhance flexibility and stabilizers to resist thermal degradation. This material is inherently resistant to water, acids, and alkalis, preventing current leakage and short circuits. The insulation is color-coded (e.g., black for phase conductors, blue for neutral) to facilitate correct wiring, adhering to international standards like IEC 60446.
PVC Sheath
The outer sheath uses a heavy-duty PVC compound with added UV stabilizers and antioxidants, enhancing its resistance to weathering. Unlike insulation-grade PVC, the sheath contains higher concentrations of fillers (e.g., calcium carbonate) to improve mechanical strength and reduce cost. It is available in standard colors (black, gray) or custom colors for easy identification in complex wiring systems.
Structural Integrity
The cable’s layers are bonded during manufacturing to prevent delamination, ensuring that the insulation and sheath remain intact even when bent or stretched. This bonding also enhances moisture resistance, as it eliminates gaps where water could seep into the conductor.
4. Manufacturing Process
The production of this cable involves a series of precision steps, from raw material preparation to final testing, ensuring compliance with international standards (e.g., IEC 60502, ASTM B800).
Conductor Formation
Aluminum ingots are melted and cast into rods, which are then drawn through dies to reduce their diameter to the required size (e.g., 2.5 mm for a 4 mm² conductor). This drawing process increases the conductor’s tensile strength through work hardening. The single strand is annealed to remove internal stresses, ensuring flexibility during installation.
Insulation Extrusion
The aluminum conductor is fed into an extrusion machine, where molten PVC (heated to 180–200°C) is applied uniformly around it. The extrusion die is calibrated to ensure precise insulation thickness, with online monitoring systems checking for defects (e.g., voids, uneven coating). The
Insulated Conductor is then cooled in a water bath to solidify the PVC.
Sheath Application
The insulated conductor is passed through a second extrusion machine to apply the outer PVC sheath. This layer is extruded at a slightly lower temperature (170–190°C) to avoid damaging the underlying insulation. The sheath is bonded to the insulation using a proprietary adhesive layer, ensuring adhesion even under thermal stress.
Quality Testing
After production, each cable undergoes rigorous testing, including:
Cables that pass all tests are spooled onto reels (ranging from 50 m to 1000 m) and labeled with specifications (e.g., conductor size, voltage rating, batch number) for traceability.
II. General Product Information
1. Packaging
The cable is packaged to ensure protection during storage, transportation, and handling, while also facilitating easy identification and installation.
Spool Packaging
Most cables are wound onto wooden or plastic spools, which vary in size based on cable length and diameter. Smaller cables (≤10 mm diameter) are typically supplied on 50 m or 100 m plastic spools, lightweight and easy to carry by hand. Larger cables (≥16 mm diameter) are wound onto 250 m, 500 m, or 1000 m wooden spools, which are mounted on pallets for stability. Each spool is fitted with a cardboard or plastic flange to prevent the cable from slipping off during transport.
Protective Wrapping
The spooled cable is wrapped in stretch film to protect against dust, moisture, and physical damage. For outdoor storage, an additional layer of waterproof tarpaulin is applied. Each spool is labeled with a barcode, product code, conductor size, length, voltage rating, manufacturing date, and compliance certifications (e.g., CE, UL).
Bulk Packaging
For large-scale projects, cables may be supplied in bulk, coiled into drums with steel frames. These drums can hold up to 5000 m of cable and are equipped with lifting eyes for easy handling by cranes or forklifts. Bulk packaging reduces packaging waste and lowers transportation costs for high-volume orders.
2. Transportation
The transportation of the cable is governed by international regulations to ensure safety and prevent damage, with specific protocols for different modes of transport.
Road Transport
Cables are transported by trucks, with spools secured using straps to prevent movement during transit. Wooden spools are placed on pallets to distribute weight evenly, while bulk drums are anchored to the truck bed using chains. For long-distance transport, climate-controlled trucks may be used to protect cables from extreme temperatures (e.g., above 70°C or below -20°C), which could degrade the PVC layers.
Sea and Air Transport
For international shipments, cables are packed into shipping containers, with spools stacked vertically to maximize space. Desiccants are placed inside containers to absorb moisture, and temperature loggers monitor conditions during transit. Air freight is used for urgent orders, with smaller spools packaged in cartons to meet weight restrictions.
Handling Guidelines
Transport personnel are trained to handle spools using appropriate equipment (e.g., forklifts with spool handlers) to avoid bending or crushing the cable. Cables must not be dragged across rough surfaces, as this can damage the sheath. Upon delivery, recipients are advised to inspect spools for signs of damage (e.g., broken flanges, torn wrapping) and report issues immediately.
3. Shipping and Delivery
The company offers flexible shipping options to meet customer deadlines, with clear processes for order processing and tracking.
Order Processing
Upon receiving an order, the production team verifies stock availability. In-stock items are processed within 24 hours, while custom orders (e.g., specific lengths or colors) may take 3–5 business days. Customers receive an order confirmation with estimated delivery dates and tracking numbers once the shipment is dispatched.
Delivery Timeframes
Shipping Costs
Shipping costs are calculated based on package weight, dimensions, and destination. Customers can choose between standard (economical) and expedited (express) shipping at checkout. Bulk orders may qualify for free shipping, with thresholds varying by region.
4. Sample Provision
To assist customers in evaluating the cable’s suitability, the company provides samples free of charge, with nominal fees for shipping.
Sample Request Process
Customers can request samples via the company website, email, or phone. They must specify the conductor size, length (up to 5 m), and intended application. Samples are typically dispatched within 48 hours of the request, with tracking information provided.
Sample Contents
Each sample includes a length of cable, a technical datasheet with specifications, and a certificate of compliance. For custom samples (e.g., special colors), customers may be required to pay a small fee, which is refundable upon placing a bulk order.
5. After-Sales Service
The company is committed to ensuring customer satisfaction, offering comprehensive support for installation, troubleshooting, and returns.
Installation Assistance
Technical engineers are available to provide guidance on cable installation, including proper termination techniques, bending radius requirements, and compliance with local electrical codes. Customers can access online resources, such as installation videos and manuals, on the company website. For large projects, on-site support may be arranged for an additional fee.
Warranty Coverage
The cable comes with a 10-year warranty against manufacturing defects, such as insulation breakdown or conductor corrosion, under normal operating conditions. The warranty does not cover damage caused by improper installation, misuse, or exposure to extreme environments beyond the cable’s rated specifications.
Returns and Replacements
If a cable is found to be defective upon delivery, customers can request a replacement within 30 days of receipt. The company may require photos or samples of the defective product to verify the issue. Returns are processed within 5–7 business days, with replacement cables shipped at no additional cost.
Customer Support
A dedicated customer service team is available 24/7 via phone, email, or live chat to address inquiries. Common issues handled include tracking shipments, resolving delivery delays, and providing technical advice. The team also conducts follow-up calls after delivery to ensure customer satisfaction and gather feedback for continuous improvement.
Conclusion
The aluminum core, single-stranded, PVC insulated, PVC sheathed cable stands out as a reliable, cost-effective solution for indoor and outdoor
Electrical Wiring. Its precise specifications, versatile applications, and robust construction make it suitable for diverse projects, while comprehensive packaging, shipping, and after-sales services ensure a seamless customer experience. By combining high-quality materials with rigorous manufacturing standards, the cable meets the demands of modern electrical systems, providing safe and efficient power transmission for years to come.
